Engine
Engine Type
Liquid-cooled, 4-stroke In-Line Four
Displacement
948
Bore x stroke
73.4 x 56 mm
Compression ratio
11.8:1
Valve/Induction system
DOHC, 16 valves
Fuel system
Fuel injection: Ø 36 mm x 4
Ignition
Digital
Starting
Electric
Lubrication
Forced lubrication, wet sump
CO2 Emission
117 g/km
Performance & Transmission
Maximum Power
85.0 kW {116 PS} / 9,300 rpm
Maximum torque
98.0 N•m {10.0 kgf•m} / 7,700 rpm
Transmission
6-speed, return
Final Drive
Chain
Clutch
Wet multi-disc, manual
Frame & Dimensions
Frame type
Trellis, high-tensile steel
Rake/Trail
Trail: 98mm
Wheel travel
Front: 120 mm | Rear: 140 mm
Steering angle
35° / 35°
Seat Height
835mm
Curb Mass
216 kg* | *Curb mass includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
Ground Clearance
135 mm
Dimensions (L x W x H)
2,100 x 865 x 1,150 mm
Fuel Capacity
17 Litres
Brakes & Suspension
Suspension front
41 mm inverted fork with compression and rebound damping and spring preload adjustability
Suspension Rear
Horizontal Back-link, gas-charged shock with rebound damping and spring preload adjustability
Brakes Front
Dual semi-floating 300 mm discs. Caliper: Dual radial-mount, monobloc, opposed 4-piston
Brakes Rear
Single 250 mm disc. Caliper: Single-piston
